4G LTE Vehicle GNSS Tracker – IP67 Waterproof Remotely Oil Cut/Resume
The MV901G is a 4G+2G dual‑network tracker with IP67 waterproof rating. Its compact body fits diverse installation spots. It supports remote fuel cut/resume, ACC detection and multiple security alarms. Multi‑satellite positioning plus 140mAh backup battery delivers stable tracking under 9‑95V wide voltage.
Características del producto
-
Remote Cut-off Fuel/PowerRemotely cut fuel or power for anti-theft protection and emergency safety control. -
ACC Status DetectionCapture vehicle ACC status for accurate activity records and asset supervision. -
Ignition On‑Off AlarmReceive instant alerts when your vehicle ignition turns on or off. Catch unauthorized activity and safeguard your car against theft. -
IP67 WaterproofWithstand temporary immersion, adapt to harsh outdoor environments. -
History Route PlaybackReplay 180 days route to trace asset paths and secure your assets. -
Geo-fenceGet alerts for unauthorized zone crossings, restrict vehicle activity range. -
Real-time TrackingMonitor your asset location live, keep full control all the time. -
Movement AlarmGet alerted the moment your vehicle moves, perfect for parking security. -
Vibration AlarmTrigger alerts on abnormal vibration, prevent vehicle tampering. -
Overspeed AlarmTrigger alerts when speed exceeds limit, manage reckless driving risks. -
Low Voltage AlarmMonitor car battery voltage, alert you early to avoid vehicle breakdown. -
GNSS+LBS PositioningPrecise satellite positioning, LBS backup when satellite signals drop.
- Especificaciones del producto
- Características clave
- Descargar (Manual / Catálogo)
Filtro
Device Param
|
Model
|
MV901G
|
|
Demension
|
90.6mm(L)*34mm(W)*20mm(H)
|
|
Weight
|
68g
|
|
Working Voltage
|
DC 9V - 95V
|
|
Working Temperature
|
-20℃ - 75℃
|
|
Working Humidity
|
10%-85%RH
|
|
Built-in Memory
|
3000pcs GPS data can be stored at network blind area
|
GNSS
|
Hot/Cold Start
|
<1s，<32s @ Open Sky
|
| GPS Channels | 32 |
| GNSS Antenna |
Built-in Ceramics GNSS Antenna, 25mm*25mm*4mm
|
| Positioning Type | GPS+GLONASS+LBS+AGPS |
|
GPS Frequency
|
L1: 1575.42±1.023MHz
|
|
BDS Frequency
|
B1:1561.098±2.046MHz
|
|
Accurancy |
Location accuracy: <1.5mCEP
|
|
Location accuracy: <10m（1σ）
|
|
|
Timing accuracy: <30ns（1σ）
|
|
|
Speed accuracy: <0.1m/s（1σ）
|
Cellular
| Technology |
2G GSM+4G LTE CAT1
|
|
Working Frequency
|
MV901G-SA
Module: SIMCOM A7670SA
GSM: 850/900/1800/1900MHz
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66
|
|
MV901G-EU
Module: SIMCOM A7670E
GSM: 900/1800MHz
LTE-FDD: B1/B3/B5/B7/B8/B20
|
|
| Cellular Antenna |
Built-in, FPC
|
Power
| Battery |
Built-in 3.7V 140mAh Polymer Battery |
|
Work Current |
12V/Average 40mA
|
|
Sleep Current |
12V/Average 10mA
|
Interface
| Digital Input | 1 x digital input for ignition detection |
| Digital Output | 1 x digital output for cut off oil |
| SIM Card | Normal SIM Card |
| Firmware Upgrade | OTA & UART Serial Upgrade |
| LED indication |
GSM LED |
| Charging LED | |
| GPS LED |
Certification
| Regulatory | CE, RoHS, FCC, UKCA, ISED |
